Ductile Iron Flange 2 1/2 Threaded Galvanized
The Ductile Iron Flange 2 1/2 Threaded Galvanized is a robust valve designed for industrial and commercial piping systems. It ensures one-way fluid flow while preventing backflow, making it suitable for water, air, gas, and other fluid applications. Galvanized coating...
- UQ7744023270
The Ductile Iron Flange 2 1/2 Threaded Galvanized is a robust valve designed for industrial and commercial piping systems. It ensures one-way fluid flow while preventing backflow, making it suitable for water, air, gas, and other fluid applications. Galvanized coating protects against rust and corrosion, especially in outdoor and water applications.
| Specification | Value |
|---|---|
| TYPE | Ductile Iron Flange Threaded Galvanized |
| DESIGN | Flanged Ends easy bolted connection to flanged piping systems |
| MATERIAL | Iron for tronger than cast iron, resistant to impact and stress |
| MATERIAL CONSTRUCTION | Ductile Iron |
| WEIGHT (LBS) | 7.520 |
| ADDITIONAL INFORMATION | 5-1/2″ Hole Center to Center |
| BOLT HOLE DIAMETER | 3/4″ |
| CONNECTION SIZE 1 | 2-1/2″ |
| CONNECTION SIZE 2 | 2-1/2″ |
| CONNECTION TYPE | Threaded|Threaded |
| CONNECTION TYPE 1 | Threaded |
| CONNECTION TYPE 2 | Threaded |
| DIMENSION STANDARDS | ASME B16.42/AWWA C110, ASME B1.20.1 |
| DIMENSIONS | 7″ OD x 1.12″ H |
| FINISH | Galvanized |
| FITTING TYPE | Flange |
| FLANGE THICKNESS | 0.69″ |
| NUMBER OF BOLT HOLES | 4 |
| PRESSURE CLASS | 150 lb |
| THREAD SIZE | 2-1/2-8 |
| UNIT WEIGHT KG | 3.4182 |
| APPLICATIONS | Ideal for Water & Wastewater Systems, HVAC Systems, Industrial Processes, Pumping Stations, Fire Protection Systems |
| BRAND | Midland Industries |
