A7.65 – Square D Thermal Unit, Class 20, 5.36-5.85A, 600V, Plug-On Motor Control

A7.65

A7.65 is a Square D thermal unit designed for motor control applications to protect motors and branch circuit conductors from prolonged overload currents.This thermal unit features a Class 20 trip rating with a melting alloy type S element, suitable for motor full load currents between 5.36 and 5.85 amperes. It supports a maximum voltage of 600V and mounts via a plug-on type connection. The unit is intended for use with magnetic motor starters and provides reliable overload protection by opening the control circuit contacts during overload conditions.

Key Specifications
• Manufacturer: Square D
• Part Number: A7.65
• Amperage Range: 5.36-5.85A
• Voltage Rating: 600V maximum
• Trip Class: 20
• Thermal Unit Type: Melting Alloy, Type S
• Mounting Type: Plug-On
• Application: Motor Control Overload Protection
• Compatible with Magnetic Motor Starters
• One-piece construction for easy installation
• Designed to trip within 20 seconds on overload

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A7.65
• Manufacturer : Square D
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Heater Element
• Family : A Series
• Type : A
• Full Load Amp Minimum : 4.8
• Full Load Amp Maximum : 5.44
• Full Load Amps : 5.36 to 5.85

Product Data

• UPC : 785901585398
• GTIN : 00785901585398
• Country of Origin : Mexico
• Dimensions : Depth 9.29 in (236 mm) Width 8.11 in (206 mm) Height 15.98 in (406 mm)
• Weight : 18.14
