A200MABR – Eaton Freedom NEMA Motor Control Starter Non-Reversing 9A Two-Pole

A200MABR

A200MABR is an Eaton Freedom NEMA motor control starter designed for non-reversing applications with a compact Size 00 form factor. This two-pole starter delivers reliable motor control across single-phase and three-phase systems with a 9-ampere rating and flexible horsepower ratings across multiple voltage levels. A200MABR combines proven NEMA construction with straightforward installation for industrial and commercial motor control applications. The starter features an open enclosure design and supports coil voltages of 120/240V, making it compatible with standard control circuits. UL Listed certification ensures compliance with recognized safety standards.

• Amperage Rating: 9A
• Number of Poles: Two-pole
• Series: A200
• Product Size: 00 (NEMA 0)
• Horsepower Rating: 1/3 hp at 115V, 1-1/2 hp at 208-240V, 2 hp at 480-600V
• Phase: Single-phase and three-phase
• Enclosure Type: Open
• Coil Voltage: 120/240V
• Certifications: UL Listed
• Dimensions: 4.61 in L x 4.38 in W x 3.31 in H
• Weight: 2.6 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A200MABR
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : A200 Series
• Type : A200
• Voltage : 600
• Amperage : 9
• Phase : 1
• Poles : 2
• Nema Rating : 00

Product Data

• UPC : 786678231044
• GTIN : 00786678231044
• Country of Origin : Dominican Republic
• Dimensions : 4.61 in x 3.31 in x 4.38 in (Length/Depth x Height x Width)
• Weight : 2.6 lb
• Certification : UL Listed,CSA Certified
