A200M3CACE – Cutler Hammer 90A 600V 3-Pole Size 3 Non-Reversing Motor Starter 120VAC Coil

A200M3CACE

A200M3CACE is a Cutler Hammer non-reversing motor starter designed for reliable motor control applications.This Eaton Freedom NEMA motor control starter features a 90 amp rating, three poles, and a size 3 frame. It operates at 600 volts AC and includes a 120VAC coil suitable for 120V/60 Hz or 110V/50 Hz power supplies. The starter supports motor horsepower ratings up to 25 hp at 208V, 30 hp at 240V, and 50 hp at 480/600V. It is UL Listed and CSA Certified, ensuring compliance with industry safety standards.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 90A
• Voltage: 600 VAC
• Poles: 3
• Frame Size: 3 (A200 Series)
• Coil Voltage: 120VAC (110V/50 Hz or 120V/60 Hz)
• Type: Non-Reversing Motor Starter
• Horsepower Ratings: 25 hp at 208V, 30 hp at 240V, 50 hp at 480/600V
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A200M3CACE
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Motor Starter
• Section : Motor control
• Family : A200 Series
• Type : A200
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 110

Product Data

• UPC : 786689539269
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.1
