A10AG0 – Cutler Hammer Size 00 Motor Starter 9A 3-Pole 600V NEMA

A10AG0

A10AG0 is a NEMA Size 00 three-phase motor starter from Cutler Hammer, rated for 9 amperes continuous at 600 volts with a 120V control coil. This compact magnetic motor starter is designed for general-purpose motor control applications and features a 3-pole configuration suitable for three-phase motors up to 2 horsepower at 575 volts or 1 horsepower at 230 volts. The starter includes adjustable overload protection that trips at 125% of motor current and is built to withstand 10 million mechanical operations at maximum horsepower ratings for Size 00 frames.

• NEMA Size 00 frame
• 9 ampere continuous rating
• 3-pole configuration
• 600 volt maximum
• 120 volt control coil
• Adjustable overload relay
• 10 million mechanical operations rated
• Series A1
• Suitable for general motor control

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A10AG0
• Manufacturer : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Series A1
• Type : A
• Voltage : 600
• Amperage : 9
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 120
• Nema Rating : 00

Product Data

• Weight : 2
