9999D20 – Square D 2NO Auxiliary Contact Module for 20A-90A DPA Contactors, 600V AC, NEMA B600

9999D20

9999D20 is a Square D Class 9999 auxiliary contact module with 2 normally open (2NO) contacts, designed for use with 20A to 90A DPA contactors and motor starters. This auxiliary contact module provides reliable control circuit signaling and is rated for up to 600V AC with a NEMA B600 contact rating. It features quick-connect terminals and binder head screws for easy wiring, and its compact design supports DIN rail mounting for reduced installation costs.

• Manufacturer: Square D
• Part Number: 9999D20
• Series/Frame: Class 9999, DPA
• Contact Configuration: 2NO
• Rated Current: 3A at 120V AC, 1.5A at 240V AC
• Maximum Voltage: 600V AC
• Mounting Type: DIN rail
• Interrupt Rating: NEMA B600
• Standards: UL Component Recognized, CSA Certified
• Wiring: Quick connect terminals, binder head screws
• Application: 20A to 90A DPA contactors and motor starters
• Country of Origin: China

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 9999D20
• Manufacturer : Square D
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor And Motor Starter Auxiliary
• Family : Class 9999
• Type : DPR
• Voltage : 600 AC
• Configuration : 2NO
• Aux Contacts : 2 NO

Product Data

• UPC : 785901081319
• GTIN : 00785901081319
• Country of Origin : China
• Dimensions : Depth 9.13 in (232 mm) Width 21.69 in (551 mm) Height 8.50 in (216 mm)
• Weight : 0.09
• Certification : CSA Approved, UL Recognized
