8910DPA33V04 – Square D 30A 277V 3 Pole Definite Purpose Contactor, 3 Phase, Panel Mount

8910DPA33V04

8910DPA33V04 is a Square D definite purpose contactor designed for motor control applications.This 3 pole, 3 phase contactor features a 30 ampere full load rating with a 277 VAC coil voltage and panel mounting type. It supports motor horsepower ratings of 2 HP at 115 VAC single phase, 10 HP at 230 VAC, and 15 HP at 460/575 VAC. The contactor is normally open with a non-reversing configuration and is suitable for use up to 600 VAC.

Key Specifications
• Amperage: 30A
• Voltage: 277 VAC coil, 600 VAC max operational
• Poles: 3
• Phase: 3
• Mounting Type: Panel mount
• Contactor Type: Definite Purpose
• Contact Configuration: 3 Normally Open (3NO)
• Horsepower Ratings: 2 HP @ 115 VAC, 10 HP @ 230 VAC, 15 HP @ 460/575 VAC
• Non-Reversing
• Series: DPA
• Interrupt Rating: Not explicitly specified
• Certifications: Not explicitly specified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Definite Purpose Contactor includes a 277 VAC coil.

Specifications

• Part Number: 8910DPA33V04
• Manufacturer : Square D
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 8910
• Type : DPA
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• Horse Power : 2 hp 115 V AC, 1 phase-5 hp 230 V AC, 1 phase-10 hp 230 V AC, 3 phases-15 hp 460 V AC, 3 phases-20 hp 575 V AC, 3 phases
• Aux Contacts : 3 NO
• Coil Voltage Maximum : 277V
• Full Load Amps : Full Load Amps-Inductive 30A Full Load Amps-Resistive 40A
• Coil Voltage Minimum : 277V
• Frequency : 60 Hz

Product Data

• UPC : 785901024422
• GTIN : 00785901024422
• Country of Origin : China
• Dimensions : 2.37 in x 2.31 in
• Weight : 1
• Certification : CSA, RoHS, UL Listed
