8910DPA13V04 – Square D 20A 3-Pole 600V Definite Purpose Contactor

8910DPA13V04

8910DPA13V04 is a Square D Class 8910 Definite Purpose Contactor designed for reliable motor control applications in industrial and commercial settings. This 3-pole contactor features a 20A line rated amperage with 600V AC rated voltage and a 277V AC coil, making it suitable for three-phase motor control circuits. The unit utilizes quick connect terminals and binder head screws for straightforward installation and maintenance. Key Specifications

• Part Number: 8910DPA13V04
• Manufacturer: Square D (Schneider Electric)
• Type: Definite Purpose Contactor
• Poles: 3
• Line Rated Amperage: 20A
• Voltage Rating: 600V AC
• Coil Voltage: 277V AC
• Locked Rotor Rated Current: 120A at 277V AC
• Electrical Connection: Quick Connect Terminals with Binder Head Screws
• Construction: Open Frame
• Class: 8910

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 8910DPA13V04
• Manufacturer : Square D
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 8910
• Type : DPA
• Voltage : 600
• Amperage : 20
• Phase : 3
• Poles : 3
• Horse Power : 1.5 hp 115 V AC, 1 phase-3 hp 230 V AC, 1 phase-7.5 hp 230 V AC, 3 phases-7.5 hp 460 V AC, 3 phases-7.5 hp 575 V AC, 3 phases
• Aux Contacts : 3 NO
• Coil Voltage Maximum : 277V
• Coil Voltage Minimum : 277V

Product Data

• Weight : 1
• Certification : UL recognized CSA
