8910DP32V09Y135 – Schneider Electric 30A 2-Pole Definite Purpose Contactor 208/240 VAC Coil DIN Rail Mount

8910DP32V09Y135

8910DP32V09Y135 is a Schneider Electric definite purpose contactor with a 30 amp full load rating and 2 poles designed for motor control applications.This contactor features a coil voltage of 208/240 VAC at 60 Hz and 220 VAC at 50 Hz, with an open design and DIN rail mounting for easy installation. It supports motor horsepower ratings of 2 HP at 115 VAC single-phase and 5 HP at 230 VAC single-phase. The contactor includes 2 normally open auxiliary contacts and is UL recognized and CSA certified.

• Amperage: 30 A full load
• Poles: 2
• Coil Voltage: 208/240 VAC 60 Hz, 220 VAC 50 Hz
• Horsepower Rating: 2 HP @ 115 VAC 1 Phase, 5 HP @ 230 VAC 1 Phase
• Mounting Type: DIN Rail
• Auxiliary Contacts: 2 Normally Open (NO)
• Type: Definite Purpose Contactor
• Certifications: UL Recognized, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 8910DP32V09Y135
• Manufacturer : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Horse Power : 2 hp 115 V AC, 1 phase-5 hp 230 V AC, 1 phase
• Aux Contacts : 2 NO
• Coil Voltage Maximum : 220V
• Coil Voltage Minimum : 220V

Product Data

• Weight : 0.6
• Certification : UL recognized CSA
