8910DP11V14 – Square D 20A 600V 1 Pole Definite Purpose Contactor 24V Coil Class 8910

8910DP11V14

8910DP11V14 is a Square D Class 8910 definite purpose contactor designed for motor control applications.This contactor features a 20 ampere rating, 600 volts maximum voltage, and a single pole configuration with a 24 VAC coil. It supports 1 hp at 115 V AC and 2 hp at 230 V AC for single-phase motors. The device is ideal for use in heating, air conditioning, refrigeration, and other equipment requiring reliable motor control.

• Manufacturer: Square D
• Part Number: 8910DP11V14
• Class: 8910
• Amperage: 20 A
• Voltage: 600 V max
• Poles: 1
• Coil Voltage: 24 VAC
• Horsepower Rating: 1 hp at 115 V AC, 2 hp at 230 V AC
• Phase: Single-phase
• Mounting Type: Panel mount (typical for definite purpose contactors)
• Contact Configuration: 1 Normally Open (NO)
• Application: Motor control for HVAC, refrigeration, and food service equipment

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 8910DP11V14
• Manufacturer : Square D
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 8910
• Type : DP
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 1
• Horse Power : 1 hp 115 V AC, 1 phase-2 hp 230 V AC, 1 phase
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 24V
• Coil Voltage Minimum : 24V

Product Data

• UPC : 782113973548
• GTIN : 00785901080480
• Dimensions : Depth 4.13 in (104.90 mm) Width 4.5 in (114.30 mm) Height 6.4 in (162.56 mm)
• Weight : 1
• Certification : UL recognized CSA
