800T-A9A – Allen-Bradley 30mm Flush Head Momentary Push Button, 1NO 1NC, 600V, 10A, NEMA 4/13

800T-A9A

800T-A9A is a 30mm flush head momentary push button from Allen-Bradley designed for motor control applications.This push button features a yellow plastic round operator cap with a flush head design and momentary contact action. It includes a standard contact block with 1 normally open (NO) and 1 normally closed (NC) contact rated for 10A at up to 600V AC/DC. The device supports screw connections with finger-safe covers and is rated for NEMA 4 and 13 enclosures, suitable for harsh environments. It is certified by ABS, CCC, CE, CSA, EAC, GOST, and UL.

• Operator size: 30 mm
• Contact configuration: 1 NO, 1 NC
• Contact rating: 10 A, 600 V AC/DC max
• Operator type: Flush head push button
• Momentary action
• Mounting hole diameter: 30.5 mm
• Termination: Screw connection with finger-safe covers
• NEMA enclosure rating: 4, 13
• Certifications: ABS, CCC, CE, CSA, EAC, GOST, UL
• Operator material: Plastic
• Contact block life: 1,000,000 cycles at max load
• Operating temperature: -25 C to 50 % humidity

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 800T-A9A
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory
• Compatible Frames : TED

Product Data

• UPC : 781180607950
• GTIN : 00781180607585
• Weight : 1 lb
