505C806G18 – Westinghouse/Cutler Hammer 277V AC Magnetic Coil for A200/A201 Series Starters & Contactors, Size 00-2, 2/3/4/5 Pole, Model J, 60 Hz

505C806G18

505C806G18 is a Westinghouse/Cutler Hammer magnetic coil designed for A200 and A201 series starters and contactors, providing reliable motor control in industrial applications.

This 277V AC magnetic coil is compatible with Model J contactors and starters in sizes 00, 0, 1, and 2, supporting 2, 3, 4, and 5 pole configurations. It is engineered for 60 Hz operation and is a direct replacement for original equipment, ensuring seamless integration and performance.

Key Specifications
• Part Number: 505C806G18
• Manufacturer: Westinghouse/Cutler Hammer
• Voltage: 277V AC
• Frequency: 60 Hz
• Series/Frame: A200/A201, Model J, Size 00-2
• Poles: 2, 3, 4, 5
• Mounting Type: Magnetic contactor/starter coil
• Application: Motor control, starters, contactors
• Certifications: Meets NEMA standards (exact certification not specified in available data)
• Amperage: Not specified in available data
• Interrupt Rating: Not specified in available data
• Trip Unit: Not applicable (coil only)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 505C806G18
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Magnetic Coil
• Family : A200 Series
• Type : 505
• Voltage : 277

Product Data

• UPC : 786678828787
• GTIN : 00786678828787
• Country of Origin : United States
• Dimensions : 3.4 in x 1.5 in x 1.9 in (Length/Depth x Height x Width)
• Weight : 0.2
