505C806G02 – Westinghouse/Cutler Hammer A200 Series 3 Pole Magnetic Coil, 208V 60Hz, Size 00/0/1/2, 5HP Max, Thermal Overload Relay BA13A, 30A Max, 600VAC Interrupt Rating, Motor Control

505C806G02

505C806G02 is a Westinghouse/Cutler Hammer A200 series magnetic coil designed for motor control applications.

This replacement coil is compatible with A200 size 00, 0, 1, and 2 three-pole motor controllers, providing reliable operation for full voltage starters with overload protection. It is engineered for use in industrial environments where consistent performance and durability are essential.

Key Specifications

• Part Number: 505C806G02
• Manufacturer: Westinghouse/Cutler Hammer
• Category: Motor Control
• Voltage: 208V AC
• Frequency: 60Hz
• Poles: 3
• Series/Frame: A200, Size 00, 0, 1, 2
• Maximum Horsepower: 5HP
• Thermal Overload Relay: BA13A
• Maximum Amperage: 30A
• Interrupt Rating: 600VAC
• Mounting Type: Panel or enclosure (specifics not specified)
• Trip Unit: Thermal overload (BA13A)
• Certifications: Not specified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 505C806G02
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Magnetic Coil
• Family : A200 Series
• Type : 505
• Voltage : 208

Product Data

• UPC : 786678707129
• GTIN : 00786678707129
• Country of Origin : United States
• Dimensions : 1.4 in x 1.4 in x 1.8 in (Length/Depth x Height x Width)
• Weight : 0.35 lb
