505-BOD-23 – Allen-Bradley 27A 600V 3-5 Pole NEMA Size 1 Reversing Starter Coil 115/120V

505-BOD-23

505-BOD-23 is an Allen-Bradley reversing starter designed for industrial motor control applications with a 27 amp continuous current rating and 600 volt capacity.This NEMA Size 1 open-style reversing starter supports full-voltage reversing of three-phase motors. It features a coil voltage of 115/120 V AC at 60 Hz and is rated for a service limit current of 32 amps. The device accommodates 3 to 5 poles and is built for vertical mounting with corrosion-resistant metal parts. It does not include an overload relay and is suitable for control voltages up to 600 VAC.

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Part Number: 505-BOD-23
• Continuous Current Rating: 27 Amps
• Service Limit Current: 32 Amps
• Voltage Rating: Up to 600 V AC
• Coil Voltage: 115/120 V AC, 60 Hz
• Poles: 3 to 5 poles
• Mounting Type: Vertical
• Enclosure: Open NEMA Size 1
• Overload Relay: None
• Corrosion Resistance: Treated metal parts
• Application: Motor reversing starter

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 505-BOD-23
• Manufacturer : Allen-Bradley
• Brand : Allen-Bradley
• Category : Motor Control
• Item Subcategory : Motor Starter
• Voltage : 600
• Amperage : 27
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 120
• Nema Rating : 1
• Compatible Frames : HMCPS

Product Data

• UPC : 781180162473
• GTIN : 10781180156233
• Weight : 15 lb
