48ATC3S00 – Siemens 3-12 Amp 3 Pole Solid State Overload Relay Frame A1 ESP200

48ATC3S00

48ATC3S00 is a Siemens solid state overload relay designed for motor protection with a current range of 3 to 12 amps and 3 poles.This ESP200 series relay features selectable trip classes (5/10/20/30), auto/manual/remote reset options, and direct mounting compatibility with A1 frame contactors.

Key Specifications
• Current Range: 3.0-12.0 Amps
• Poles: 3
• Frame Size: A1
• Trip Class: Selectable 5, 10, 20, 30
• Reset Type: Auto, Manual, Remote
• Mounting: DIN Rail or direct mount
• Phase Monitoring: Phase loss and unbalance selectable
• Contact Configuration: 1 NO, 1 NC auxiliary contacts
• Voltage Rating: Up to 600 VAC
• Standards: UL Listed, cUL, CSA Certified
• Operating Temperature: -25 to 60 C
• Special Features: Electronic trip, ground fault selectable

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 48ATC3S00
• Manufacturer : Siemens
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Overload Relay
• Family : ESP200
• Type : 48AT
• Relay Style : Solid State
• Amperage Maximum : 12
• Amperage Minimum : 3

Product Data

• UPC : 662643897203
• Weight : 10
