3RU1116-1DB0 – Siemens 3-Pole Thermal Overload Relay 2.2-3.2A Size S00 Motor Protection

3RU1116-1DB0

3RU1116-1DB0 is a Siemens thermal overload relay designed for motor protection with adjustable current settings from 2.2 to 3.2 amps.

This Siemens Sirius 3-pole thermal overload relay mounts directly to Siemens 3RT1 size S00 contactors and features class 10 tripping with phase loss sensitivity. It includes manual and automatic reset options, screw terminal connections, and an integrated sealable cover for secure operation. The relay is rated for use up to 690 VAC and provides reliable protection for three-phase motors.

Key Specifications
• Adjustable current range: 2.2 to 3.2 Amps
• Number of poles: 3
• Size: S00 frame
• Tripping class: 10
• Mounting type: Direct mount to 3RT1 contactors
• Voltage rating: Up to 690 VAC
• Terminal type: Screw terminals
• Phase loss sensitivity included
• Manual and automatic reset options
• Integrated sealable cover

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3RU1116-1DB0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Overload Relay
• Family : Sirius
• Type : 3RU11
• Relay Style : Thermal
• Amperage Maximum : 3.2
• Amperage Minimum : 2.2

Product Data

• Weight : 1
