3RU1116-0BB0 – Siemens 0.14-0.20A Thermal Overload Relay for S00 Contactors Class 10 Trip

3RU1116-0BB0

3RU1116-0BB0 is a Siemens Sirius thermal overload relay designed for motor protection with adjustable current settings and Class 10 tripping. This overload relay provides reliable protection for three-phase and single-phase AC and DC motors, featuring phase loss sensitivity and manual or automatic reset options. It mounts directly to Siemens 3RT1 size S00 contactors (3RT1015, 3RT1016, 3RT1017) and can also be separately mounted using a DIN rail or base bracket. The relay uses screw terminals for both main and auxiliary circuits, ensuring secure connections and easy installation.

• Adjustable current range: 0.14 to 0.20 A
• Class 10 tripping (trips in 10 seconds or less)
• Phase loss protection included
• Manual or automatic reset
• Mounts directly to 3RT1 size S00 contactors
• Separate mounting possible with DIN rail or base bracket
• Main circuit: screw terminal
• Auxiliary circuit: screw terminal
• 1 NC auxiliary contact
• 1 NO auxiliary contact
• For use with 3RT1015, 3RT1016, 3RT1017 contactors

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3RU1116-0BB0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Overload Relay
• Family : Sirius
• Type : 3RU11
• Relay Style : Thermal
• Amperage Maximum : 0.2
• Amperage Minimum : 0.14

Product Data

• GTIN : 04011209286849
• Weight : 0.3212
