3RT20161AP01 – Siemens 9 Amp 3-Pole Motor Contactor 230V AC Coil DIN Rail Mount

3RT20161AP01

3RT20161AP01 is a Siemens 3-pole motor contactor with a 9 amp AC-3 rating and a 230V AC coil designed for reliable motor control applications.This Siemens Sirius contactor features screw terminals and supports DIN rail or screw mounting. It is rated for 3 HP at 230V and 5 HP at 460V for three-phase motors. The device includes one normally open auxiliary contact and is suitable for side-by-side mounting. It supports a coil voltage of 230V AC at 50/60 Hz and has a compact design with dimensions 58 mm height, 45 mm width, and 73 mm depth. The contactor requires a 10 A gG fuse for auxiliary switch short-circuit protection and complies with UL contact ratings A600/Q600.

Key Specifications
• Amperage: 9 A AC-3
• Voltage: 230 V AC Coil
• Number of Poles: 3
• Mounting Type: DIN rail or screw mount
• Auxiliary Contacts: 1 Normally Open (NO)
• Horsepower Ratings: 3 HP @ 230 V, 5 HP @ 460 V (3-phase)
• Coil Frequency: 50/60 Hz
• Dimensions: 58 mm H x 45 mm W x 73 mm D
• Short-Circuit Protection: Requires 10 A gG fuse for auxiliary switch
• UL Contact Rating: A600 / Q600

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3RT20161AP01
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Contactors
• Section : Contactors

Product Data

• UPC : 662643907728
• Country of Origin : Germany
• Dimensions : 2.421 x 1.969 x 3.051 inch
• Weight : 0.514 lb
