3RT1025-1DB44-0KV0 – Siemens 3 Pole 3 Phase 17A 600V Sirius Contactor with 24V DC Coil

3RT1025-1DB44-0KV0

3RT1025-1DB44-0KV0 is a Siemens Sirius 3-pole, 3-phase contactor designed for motor control applications with a 24V DC coil.

This Siemens contactor is rated for 17 amps AC-3 duty and supports motor loads up to 7.5 kW at 400V. It features a Size S0 frame and includes an auxiliary switch block with 2 normally open (NO) and 2 normally closed (NC) contacts, as well as a built-in varistor for coil protection. This device is suitable for controlling three-phase motors and other AC loads up to 600V.

• Manufacturer: Siemens
• Part Number: 3RT1025-1DB44-0KV0
• Poles: 3
• Phase: 3-phase
• Rated Current: 17 A (AC-3)
• Rated Power: 7.5 kW at 400 V
• Coil Voltage: 24 V DC
• Frame Size: S0
• Auxiliary Contacts: 2 NO + 2 NC
• Built-in Varistor for coil protection
• Maximum Voltage: 600 V

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3RT1025-1DB44-0KV0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Sirius
• Type : 3RT10
• Voltage : 600
• Amperage : 17
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 24
• Coil Voltage Minimum : 24

Product Data

• Weight : 1
