2601BW1 – Square D 5HP 575VAC Reversing Drum Switch NEMA 4 Handle Operated

2601BW1

2601BW1 is a Square D reversing drum switch designed for reliable motor control in industrial applications. This switch features a standard handle actuator and is rated for 5 HP at 575 VAC single phase and 7.5 HP at 575 VAC polyphase. The NEMA 4 enclosure provides protection against dust and water, making it suitable for demanding environments. This reversing drum switch is ideal for applications requiring manual motor direction control. It supports a wide voltage range, from 115 VAC minimum to 600 VAC maximum, and is suitable for both single-phase and polyphase motors. The robust construction ensures long-term durability and safe operation.

• Reversing type drum switch
• 5 HP at 575 VAC single phase
• 7.5 HP at 575 VAC polyphase
• 115 VAC minimum, 600 VAC maximum
• 115 VDC minimum, 250 VDC maximum
• Handle operated actuator
• NEMA 4 enclosure
• UL and CSA certified
• 5.5 inch diameter x 6.89 inch height
• Reversing motor control
• Industrial grade construction
• Manual operation

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 2601BW1
• Manufacturer : Square D
• Brand : ABB
• Category : Motor Control
• Item Subcategory : Switches
• Section : Drum switch
• Family : B Series
• Voltage : 600 , 250 DC 600 /250 DC

Product Data

• UPC : 785901784449
• GTIN : 785901784449
• Country of Origin : Mexico
• Dimensions : 5.5 in W x 6.89 in H 6.89 in H x 5.5 in W
• Weight : 3.5 lb
• Certification : CSA Cetrified, UL Listed
