2510FW2 – Schneider Electric Square D Type F 2-Speed Drum Switch, 600 V, Open Type

2510FW2

2510FW2 is a 2-speed drum switch manufactured by Schneider Electric / Square D as part of the Type F manual control line. It provides manual control of two-speed motors by reversing or changing motor connections and is rated for up to 600 V AC. This open-type switch is panel-mounted and ideal for industrial equipment where dependable, direct motor control is needed. The 2510FW2 features a durable cam-operated mechanism with silver contacts and a maintained handle position. It allows precise manual operation of two-speed or multi-winding motors.

• Part Number: 2510FW2
• Manufacturer: Schneider Electric / Square D
• Series / Family: Type F Manual Motor Controllers
• Product Type: 2-Speed Drum Switch
• Voltage Rating: Up to 600 V AC
• Phase: Single or three-phase
• Enclosure Type: Open (panel mount)
• Handle Action: Maintained, multi-position
• Poles: 3-pole configuration (typical)
• Mounting Type: Panel mount with screw terminals
• Application: Manual control of 2-speed motors, hoists, and reversing drives
• Compliance: UL Listed, CSA Certified, NEMA Standard

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Non-Reversing

Specifications

• Part Number: 2510FW2
• Manufacturer : Square D
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Class 2510
• Type : F
• Voltage : 277
• Amperage : 16
• Phase : 1
• Poles : 2

Product Data

• UPC : 785901554356
• GTIN : 00785901554356
• Country of Origin : Mexico
• Dimensions : 4.25 in x 4.56 in
• Weight : 1.33 lb
• Certification : CSA LR25490, E42243 CCN NLRV, UL Listed
