2510FG5 – Square D 16A 1 Pole Manual Motor Starter 1 HP 277VAC NEMA 1 Key Operated

2510FG5

2510FG5 is a Square D manual motor starter designed for fractional horsepower motor control applications.This manual starter features a 16 ampere rating, 1 pole configuration, and supports motors up to 1 HP at 277 VAC. It includes a key-operated guard for added safety and comes in a NEMA 1 enclosure suitable for indoor use. The device provides thermal protection and is ideal for non-reversing motor control.

• Manufacturer: Square D
• Part Number: 2510FG5
• Amperage: 16A
• Poles: 1
• Voltage: 277 VAC
• Horsepower Rating: 1 HP
• Mounting Type: Panel Mount
• Enclosure: NEMA 1
• Operation: Key Operated with Guard
• Trip Unit: Thermal Protection
• Phase: Single Phase

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Non-Reversing

Specifications

• Part Number: 2510FG5
• Manufacturer : Square D
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Class 2510
• Type : F
• Voltage : 277
• Amperage : 16
• Phase : 1
• Poles : 1
• Nema Rating : 00

Product Data

• UPC : 785901554011
• GTIN : 00785901554011
• Country of Origin : Mexico
• Dimensions : 4.25 in x 2.88 in
• Weight : 0.81
• Certification : CSA LR25490, E42243 CCN NLRV, UL Listed
