2510FG2 – General Electric 16A 277V 2-Pole Manual Motor Starter NEMA 1

2510FG2

2510FG2 is a General Electric manual motor starter designed for fractional horsepower motor control applications.This 2-pole, non-reversing manual starter features a 16 ampere current rating and operates at 277 volts AC. It supports up to 1 horsepower at 277 VAC and is housed in a NEMA 1 enclosure suitable for surface mounting. The starter uses a toggle switch operation without an indicator and complies with standard motor control requirements. Heater packs are sold separately.

Key Specifications
• Manufacturer: General Electric
• Part Number: 2510FG2
• Current Rating: 16 Amps
• Voltage: 277 VAC
• Poles: 2
• Horsepower Rating: 1 HP at 277 VAC
• Mounting Type: Surface Mount
• Enclosure: NEMA 1
• Operation: Toggle Switch, Non-Reversing
• Trip Unit: Manual Starter
• Heater Packs: Sold Separately

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Non-Reversing

Specifications

• Part Number: 2510FG2
• Manufacturer : General Electric
• Brand : General Electric
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : Class 2510
• Type : F
• Voltage : 277
• Amperage : 16
• Phase : 1
• Poles : 2
• Nema Rating : 00

Product Data

• UPC : 785901553953
• GTIN : 00785901553953
• Country of Origin : Mexico
• Dimensions : 4.25 in x 2.75 in
• Weight : 0.79
• Certification : CSA LR25490, E42243 CCN NLRV, UL Listed
